Question

The room is 20 ft by 20 ft wide and 9 ft high. The floor is at 100°F, the walls are at 60°F, and the ceiling is at 40°F. All surfaces are assumed to be black. Calculate the net radiation heat transfer (a) from the floor to the walls and (b) from the floor to the ceiling.

Name: the room is 20 ft by 20 ft wide and 9 ft high the floor is at 100f the walls are at 60f and the ceiling is at 40f all surfaces are assumed black calculate the net radiation heat transfer a f 29236
Uploaded: 2022-05-08T10:29:50-08:00
Duration: 2 min 46 s
Channel: Animesh Raj
Description: the room is 20 ft by 20 ft wide and 9 ft high the floor is at 100f the walls are at 60f and the ceiling is at 40f all surfaces are assumed black calculate the net radiation heat transfer a f 29236

          The room is 20 ft by 20 ft wide and 9 ft high. The floor is at 100°F, the walls are at 60°F, and the ceiling is at 40°F. All surfaces are assumed to be black. Calculate the net radiation heat transfer (a) from the floor to the walls and (b) from the floor to the ceiling.

Added by Kirk A.

University Physics with Modern Physics

Hugh D. Young 14th Edition

Instant Answer

Solved by Expert Animesh Raj

05/08/2022

Step 1

Given: Length of room (L) = 20 ft Width of room (W) = 20 ft Height of room (H) = 9 ft Calculate the ratio L/(L+W): L/(L+W) = 20/(20+20) = 20/40 = 0.5 Calculate the view factor (F) from the floor to the walls using the formula: F = 4*(L/(L+W)) = 4*0.5 = 2 Show more…

Show all steps
