The solid shaft with a 100mm diameter shown below is subjected to a force of 30P which acts along the
axis of the shaft and is applied at the center of the shaft and a force P which is applied in the y direction 600
mm from the z=0 axis.
a) Determine the internal forces and moments at a plane containing points A and B and
perpendicular to the x-axis (be sure to specify all of them)
b) Determine the state of stress at point A which lies on the surface of the shaft along the y axis
in terms of the load P.
c) Determine the state of stress at point B which lies on the surface of the shaft along the z axis
in terms of the load P.
The solid shaft with a 100 mm diameter shown below is subjected to a force of 30P which acts along the axis of the shaft and is applied at the center of the shaft and a force P which is applied in the y direction 600 mm from the z = 0 axis.
a) Determine the internal forces and moments at a plane containing points A and B and perpendicular to the x-axis (be sure to specify all of them) b)Determine the state of stress at point A which lies on the surface of the shaft along the y axis in terms of the load P
c Determine the state of stress at point B which lies on the surface of the shaft along the z axis in terms of the load P.
30
750
