1. A simple Rankine cycle works between pressure of 30 bar and 0.04 bar, the initial condition of steam being dry saturated, calculate the cycle efficiency, work ratio and specific steam consumption. [Ans. 35%, 0.997, 3.84 kg/kWh]
2. A steam power plant works between 40 bar and 0.05 bar. If the steam supplied is dry saturated and the cycle of operation is Rankine, find :
(i) Cycle efficiency
(ii) Specific steam consumption.
[Ans. (i) 35.5%, (ii) 3.8 kg/kWh]
3. Compare the Rankine efficiency of a high pressure plant operating from 80 bar and 400°C and a low pressure plant operating from 40 bar 400°C, if the condenser pressure in both cases is 0.07 bar. [Ans. 0.391 and 0.357]
4. A steam power plant working on Rankine cycle has the range of operation from 40 bar dry saturated to 0.05 bar. Determine :
(i) The cycle efficiency
(ii) Work ratio
(iii) Specific fuel consumption.
[Ans. (i) 34.64%, (ii) 0.9957, (iii) 3.8 kg/kWh]
5. In a Rankine cycle, the steam at inlet to turbine is saturated at a pressure of 30 bar and the exhaust pressure is 0.25 bar. Determine :
(i) The pump work
(ii) Turbine work
(iii) Rankine efficiency
(iv) Condenser heat flow
(v) Dryness at the end of expansion.
Assume flow rate of 10 kg/s.
[Ans. (i) 30 kW, (ii) 7410 kW, (iii) 29.2%, (iv) 17900 kW, (v) 0.763]
6. In a regenerative cycle the inlet conditions are 40 bar and 400°C. Steam is bled at 10 bar in regenerative heating. The exit pressure is 0.8 bar. Neglecting pump work determine the efficiency of the cycle.
[Ans. 0.296]
