Three 3-phase balanced loads are connected in parallel across a 400-V, 3-phase, 3-wire balanced supply. Load 1: 12 kW, delta-connected, pf =1 Load 2: 9 kVA, wye connected load, pf = 0.866 lagging Load 3: 6 kVAR, delta-connected, pf = 0, capacitive Find the total current drawn from the line.
