Question

Three capacitors of 5?F,10?F and 15?F are first connected in series and then in parallel with a supply of 100V. Find (1) the equivalent capacitance in case and (2) charge on each capacitor in each case.

Name: three capacitors of 5f10f and 15f are first connected in series and then in parallel with a supply of 100v find 1 the equivalent capacitance in case and 2 charge on each capacitor in each case
Uploaded: 2022-02-24T10:05:55-08:00
Duration: 2 min 30 s
Channel: Kamlesh Goyal
Description: three capacitors of 5f10f and 15f are first connected in series and then in parallel with a supply of 100v find 1 the equivalent capacitance in case and 2 charge on each capacitor in each case

          Three capacitors of 5?F,10?F and 15?F are first connected in series and then in parallel with a supply of 100V. Find (1) the equivalent capacitance in case and (2) charge on each capacitor in each case.

Added by Arun B.

Fundamentals of Electric Circuits

Charles K. Alexander, Matthew N.O.… 3rd Edition

Chapter 6

Instant Answer

Solved by Expert Kamlesh Goyal

02/24/2022

Step 1

Given: \(C_1 = 5 \mu F\), \(C_2 = 10 \mu F\), \(C_3 = 15 \mu F\). The equivalent capacitance in series is given by: \(\frac{1}{C_s} = \frac{1}{C_1} + \frac{1}{C_2} + \frac{1}{C_3}\), \(\frac{1}{C_s} = \frac{1}{5} + \frac{1}{10} + \frac{1}{15}\), \(\frac{1}{C_s} = Show more…

Show all steps
