Question

Two blocks are connected by a string that goes over an ideal pulley as shown in the figure. Block m1 has a mass of 3.77 kg and can slide over a rough plane inclined 29° to the horizontal. The coefficient of kinetic friction between block A and the plane is 0.665. Block B has a mass of 4.13 kg. What is the acceleration of the blocks?

Name: two blocks are connected by a string that goes over an ideal pulley as shown in the figure block m1 has a mass of 377 kg and can slide over a rough plane inclined 29 to the horizontal the co 66248
Uploaded: 2022-10-10T18:57:42-08:00
Duration: 4 min 29 s
Channel: Ivan Kochetkov
Description: two blocks are connected by a string that goes over an ideal pulley as shown in the figure block m1 has a mass of 377 kg and can slide over a rough plane inclined 29 to the horizontal the co 66248

          Two blocks are connected by a string that goes over an ideal
pulley as shown in the figure. Block m1 has a mass of 3.77 kg and
can slide over a rough plane inclined 29° to the horizontal. The
coefficient of kinetic friction between block A and the plane is
0.665. Block B has a mass of 4.13 kg. What is the acceleration of
the blocks?

Added by Timothy W.

University Physics with Modern Physics

Hugh D. Young 14th Edition

Instant Answer

Solved by Expert Ivan Kochetkov

10/10/2022

Step 1

Step 1: Write down the equations of motion for each block: For block B: \(m_b g - T = m_b a\) For block A: \(T - m_1 g \sin(\alpha) - \mu_k m_1 g \cos(\alpha) = m_1 a\) Show more…

Show all steps

Thanks for your feedback!

Two blocks are connected by a string that goes over an ideal pulley as shown in the figure. Block m1 has a mass of 3.77 kg and can slide over a rough plane inclined 29° to the horizontal. The coefficient of kinetic friction between block A and the plane is 0.665. Block B has a mass of 4.13 kg. What is the acceleration of the blocks?
