0:00
All right, hello.
00:01
In this question, we're given this setup.
00:02
We have two current -carrying wires carrying currents in opposite directions.
00:04
And we know the current on the right wire.
00:06
We don't know the current on the left wire.
00:08
But we do know that it's pointing down.
00:10
And we're told that the magnetic field at point c here, bc, is going to be equal to 0.
00:16
And with that information, we want to figure out what i1 is going to be.
00:19
So in order to do this, we need to figure out what the direction of these magnetic fields is going to be pointing.
00:23
I take my right hand and point my thumb down the page for the left wire here and curl my fingers.
00:28
On the right side, i'm going to have a magnetic field that comes out of the page, because that's the way my fingers are going to be pointing.
00:35
And so it's going to be on the right side all around.
00:38
And at point c, b1 is coming out of the page.
00:41
So that's b1 in red.
00:43
Likewise, if i point my thumb up the page and curl my fingers on the right, i'm going to have them pointing away from me.
00:48
So b2 is going to be pointing away from me on the right side here.
00:52
And it's going to be pointing towards me on the left side.
00:56
So it's going to be pointing out there as well.
00:58
So i know that my magnetic field at point c as a vector is going to be b1 plus b2.
01:06
And i know that those are pointing in opposite directions.
01:09
But i know this is going to equal 0.
01:11
So i know that b1 magnitude is going to equal b2 magnitude...
