8. Design a PD controller for the system shown in Figure P9.2 to reduce the settling time by a factor of 4 while continuing to operate the system with 20.5% overshoot. Compare the performance of the compensated system to that of the uncompensated system. Summarize the results in a table similar to that in Example 9.7. R(s) + [K / (s(s + 8)(s + 25))] C(s) FIGURE P9.2
