Using the answers from #7 to find #8, please find the equivalent impedance of the following load circuits at f=1 GHz:
a) RLD=50, CLD=10F
b) RLD=50, CLD=10uF
c) RLD=50, LLD=2H
d) RLD=50Q, LLD=2H
For a generator with an output real impedance of R=-50, design a match circuit to conjugate match the generator to each of the loads identified in 2 above. Identify your answers as 8a), 8b), 8c), 8d).
