DET 403 Design of Machine elements In-Class Example Review of Statics & Strength of Materials Concepts 1. A structure is loaded as shown below. Member AB is made of a \(\frac{3}{8}\) in diameter SAE 1040 HR steel. (i) Draw appropriate FBDs and determine (ii) the force in AB and the components of the reaction at support C, and (iii) the factor of safety guiding against yielding of AB. (iv) Repeat Part (iii) for member AB made of the same material but \(\frac{1}{4}\)-in diameter rod. 4 ft B 500 lb 400 lb -3 ft- -3 ft- -3 ft -3 ft- C Begin your solution here on this page
