Which of the following is not required in order to fully specify a finite state machine? Group of answer choices Specification of the material of which the machine is constituted. Specification of all states in which the machine may be. Specification of which state is the start state. Specification for each state of what to do (i.e. which state to stay in or shift to) for each possible input.
Added by Elisa R.
Step 1
An FSM typically requires the following: - A set of states. - A start state. - A transition function that defines how the machine moves from one state to another based on input. Show more…
Show all steps
Your feedback will help us improve your experience
Adi S and 98 other AP CS educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
Confused because now there are 5 states. Usually, we only have 4 states. 4a) (20 pts) Using the sequential logic design process, convert the provided state diagram (FSM) to a circuit. Be sure to label and show each step. Note: Writing the Boolean equations (in minimum sum-of-products form) is sufficient. You DO NOT need to provide a gate-level implementation (no drawing a circuit). 4b) (5 pts) If the above is a sequence detector, which sequence of b that it can detect. a) sequence 1010, non-overlapping sequence b) sequence 1010, overlapping sequence c) sequence 0101, non-overlapping sequence d) sequence 0101, overlapping sequence e) sequence 0100, non-overlapping sequence
Adi S.
Jennifer S.
Do a finite state machine that detects the sequence 101 on serial one-bit input x. One-bit output Z is 0 unless the 101 has been detected. Z should be one in any case in which the previous 3 inputs are 101, including overlapping cases. Reset = 1 should take the finite state machine back to the initial state. This is a block diagram of a generic FSM. Assume a Moore Model (Remember in a Moore model, states alone combinatorially determine output Z). If it takes 4 states to make this machine, then n = 2. And if you do {Q, x} m = 3. What to do: A) Draw a state diagram for this machine. B) Create a state assignment table for your state machine. C) Create a state transition table for your state machine. D) Find the logic to get Z from the state Q.
