Which of the statement is true about the voltages in series...

Which of the statement is true about the voltages in series circuit? ◎ Voltage splits across each resistor in series circuit. ◎ None of the options is true. ◎ All resistors get same amount of voltage in series circuit. ◎ Large resistor gets smallest voltage in series circuit.

Choose the correct statement regarding resistors in a circuit. If you connect two different resistors in series in a circuit, then the voltage across each of them is the same. Two identical resistors in series have half the resistance of each individual one. Three identical resistors in series have one-third the resistance of each individual one. Two identical resistors in parallel have half the resistance of each individual one. Three identical resistors in parallel have triple the resistance of each individual one. Remember the following formulas for resistors connected in parallel or series: Rparallel = 1/(1/R1 + 1/R2 + 1/R3, etc.) and Rseries = R1 + R2 + R3, etc. Also, resistors connected in parallel must have the same voltage, whereas resistors connected in series must have the same current flowing through each one.

Sikandar B.

Question

Which of the statement is true about the voltages in series circuit? ◎ Voltage splits across each resistor in series circuit. ◎ None of the options is true. ◎ All resistors get same amount of voltage in series circuit. ◎ Large resistor gets smallest voltage in series circuit.
