Chapter 11, Computer Animation Video Solutions, Computer Graphics with Open GL

00:52

Problem 1

Design a storyboard layout and accompanying key frames for an animation of a simple stick figure, as in Figure 17 .

Mayukh Banik

Numerade Educator

01:22

Problem 2

Write a program to generate the in-betweens for the key frames specified in Exercise 1 using linear interpolation.

Adriano Chikande

Numerade Educator

02:34

Problem 3

Expand the animation sequence in Exercise 1 to include two or more moving objects.

Supratim Pal

Numerade Educator

01:22

Problem 4

Write a program to generate the in-betweens for the key frames in Exercise 3 using linear interpolation.

Adriano Chikande

Numerade Educator

00:57

Problem 5

Write a morphing program to transform any given polygon into another specified polygon, using five in-betweens.

Monica Miller

Numerade Educator

00:48

Problem 6

Write a morphing program to transform a sphere into a specified polyhedron, using five in-betweens.

Allison Knapp

Numerade Educator

05:00

Problem 7

Set up an animation specification involving accelerations and implementing Eq. 7 .

Suzanne W.

Numerade Educator

01:03

Problem 8

Set up an animation specification involving both accelerations and decelerations, implementing the in-between spacing calculations given in Equations 7 and 8 .

James Kiss

Numerade Educator

01:00

Problem 9

Set up an animation specification implementing the acceleration-deceleration calculations of Equation $9 .$

Keshav Singh

Numerade Educator

03:17

Write a program to simulate the linear, twodimensional motion of a filled circle inside a given rectangular area. The circle is to be given an initial position and velocity, and the circle is to rebound from the walls with the angle of reflection equal to the angle of incidence.

Shelby Mohamed

Numerade Educator

19:31

Problem 11

Convert the program of the previous exercise into a two-player ball and paddle game by replacing two opposite sides of the rectangle with short line segments that can be moved back and forth along each of the rectangle edges. Interactive movement of each line segment simulates a paddle that can be positioned to prevent the bouncing ball from escaping that side of the rectangle. Each time the circle escapes from the interior of the rectangle the score of the player assigned to the opposite side is increased. Initial input parameters include circle position, direction, and speed. The game scores can be displayed in one corner of the display window.

Brian Ketelobeter

Numerade Educator

01:14

Problem 12

Modify the ball and paddle game in the previous exercise to vary the speed of the bouncing ball. After each successful block by a player, the speed of the ball is incremented by a small amount.

Kara Merfeld

Numerade Educator

02:08

Problem 13

Modify the game in the previous exercise to include two balls, each initialized to the same speed but different positions and opposite directions.

Manish Kumar ( Iit K )

Numerade Educator

02:15

Problem 14

Modify the two-dimensional bouncing ball inside a rectangle to a three-dimensional motion of a sphere bouncing around inside a parallelepiped. Interactive viewing parameters can be set to view the motion from different directions.

Mayukh Banik

Numerade Educator

06:33

Problem 15

Write a program to implement the samulation of a bouncing ball using Eq. 10 .

Willis James

Numerade Educator

02:08

Problem 16

Expand the program in the previous exercise to include squash and stretch effects.

James Kiss

Numerade Educator

19:31

Problem 17

Write a program to implement the motion of a bouncing ball using dynamics. The motion of the ball is to be governed by a downward gravitational force and a ground-plane friction force. Initially, the ball is to be projected into space with a given velocity vector.

Brian Ketelobeter

Numerade Educator

01:24

Problem 18

Write a program to implement dynamic motion specifications. Specify a scene with two or more objects, initial motion parameters, and specified forces. Then generate the animation from the solution of the force equations. (For example, the objects could be the earth, moon, and sun with attractive gravitational forces that are proportional to mass and inversely proportional to distance squared.)

Prem Bijarniya

Numerade Educator

04:10

Problem 19

Modify the rotating hexagon program in Section 10 to allow a user to interactively choose a three-dimensional object from a list of menu options to be rotated about the $y$ axis. Use a perspective projection to display the object.
