(32.2) Photon-drag radiation monitor
Figure $32-7$ shows a schematic diagram of a photon-drag radiation monitor. These devices are used to monitor the intensity of powerful laser pulses. The beam enters on the left, through an antireflection coating (Prob. 30-14) and a transparent electrode (Prob. 32-4). The body of the monitor is a single crystal of semiconductor that is quite transparent at the wavelength used. The beam exits on the right where there is, again, an antireflection coating and a transparent electrode, in that order.
Radiation pressure in the semiconductor propels the charge carriers to the right. If the carriers are electrons, the electrodes become charged, as in the figure, and the voltage $V$ is a measure of the beam power.
These monitors have a short response time, of the order of 1 nanosecond. They are made in various sizes, with crystals of the order. of 1 centimeter in diameter and a few centimeters long. The crystal absorbs about one-quarter of the pulse energy. The peak power density. can be as high as 20 megawatts/centimeter $^{2}$.
Find the ratio $V / \mathscr{S}_{m}$. Set $\mathscr{Y}=\mathscr{S}_{m} \exp (-a x)$ inside the crystal.
