Quarks and leptons: introductory course in modern particle physics

Francis Halzen, Alan D. Martin

Chapter 15

The Weinberg-Salam Model and Beyond - all with Video Answers

Educators


Chapter Questions

01:47

Problem 1

As revision, derive (15.8) and (15.9) from the statements of the above paragraph.

Manik Pulyani
Manik Pulyani
Numerade Educator
01:09

Problem 2

Show that in the Weinberg-Salam model
$$
\frac{1}{2 v^2}=\frac{g^2}{8 M_W^2}=\frac{G}{\sqrt{2}}
$$
and hence, using the empirical value of $G$ of Chapter 12, verify that $v=246$ $\mathrm{GeV}$. Derive the mass relations
$$
M_W=\frac{37.3}{\sin \theta_W} \mathrm{GeV}, \quad M_Z=\frac{74.6}{\sin 2 \theta_W} \mathrm{GeV}
$$
and give the lower bounds for their masses. Predict $M_W$ and $M_{\mathrm{Z}}$ using the experimental determination of $\sin ^2 \theta_W$.

Very recently (1983) the $\mathrm{W}$ and $\mathrm{Z}$ bosons have been discovered at the CERN $\overline{\mathrm{p}} \mathrm{p}$ collider via the processes
$$
\begin{aligned}
& \overline{\mathrm{p}} \mathrm{p} \rightarrow \mathrm{W}^{ \pm} \mathrm{X} \rightarrow\left(\mathrm{e}^{ \pm} \nu\right) \mathrm{X} \\
& \overline{\mathrm{p}} \mathrm{p} \rightarrow \mathrm{ZX} \rightarrow\left(\mathrm{e}^{+} \mathrm{e}^{-}\right) \mathrm{X},
\end{aligned}
$$
where $\mathrm{X}$ denotes all the other particles produced in the high-energy head-on collision. By studying the momentum distribution of the emitted decay electrons and positrons, the masses are measured to be
$$
\begin{aligned}
M_W & =81 \pm 2 \mathrm{GeV} \\
M_Z & =93 \pm 2 \mathrm{GeV},
\end{aligned}
$$
which are in impressive agreement with the predictions of the standard electroweak model.

Keshav Singh
Keshav Singh
Numerade Educator
04:58

Problem 3

Suppose that the Higgs scalar field $\phi(x)$ has weak isospin $T=3$ and hypercharge $Y=-4$. If the neutral component $\phi^{\circ}$ (with $T^3=2$ ) develops a vacuum expectation value $v / \sqrt{2}$, show that
$$
\begin{aligned}
M_W^2 & =\frac{g^2}{2} \phi^{\dagger}\left(T^{+} T^{-}+T^{-} T^{+}\right) \phi \\
& =4 g^2 v^2 .
\end{aligned}
$$

Keshav Singh
Keshav Singh
Numerade Educator

Problem 4

Suppose that there exist several representations $(i=$ $1, \ldots, N)$ of Higgs scalars whose charge-zero members acquire vacuum expectation values $v_i$. Show that
$$
\rho=\left(\frac{M_W}{M_Z \cos \theta_W}\right)^2=\frac{\sum v_i^2\left[T_i\left(T_i+1\right)-\frac{1}{4} Y_i^2\right]}{\sum \frac{1}{2} v_i^2 Y_i^2},
$$
where $T_i$ and $Y_i$ are, respectively, the weak isospin and hypercharge of representation $i$. Show that $\rho=1$ if only Higgs doublets with $Y_i=+1$ exist.

Check back soon!

Problem 5

The Lagrangian for the scalar field, (15.13), contains trilinear $\mathrm{hW}^{+} \mathrm{W}^{-}$and quadrilinear $\mathrm{hhW}^{+} \mathrm{W}^{-}$Higgs boson couplings. Use
$$
\phi=\sqrt{\frac{1}{2}}\left(\begin{array}{c}
0 \\
v+h(x)
\end{array}\right)
$$
[see (14.71)] to show that in the standard model the vertex factors are
$$
i g M_W \text { and } \frac{1}{4} i g^2,
$$
respectively. Determine the $\mathrm{hZZ}$ and $\mathrm{hhZZ}$ vertex factors.

Check back soon!

Problem 6

Derive (15.39), see (14.58).

Check back soon!
01:18

Problem 7

Show that
$$
\sin ^2 \theta_W=\frac{1}{1+3 C^2}\left(1+2 C^2 \frac{\alpha}{\alpha_s}\right) .
$$

Varsha Aggarwal
Varsha Aggarwal
Numerade Educator

Problem 7

In Section 15.7, we speculated that a grand unified group $G$ exists such that
$$
G \supset S U(3) \times S U(2) \times U(1) \text {. }
$$

Georgi and Glashow have shown that the smallest such group of gauge transformations is the group $S U(5)$. Of course, different GUT's with larger groups than $S U(5)$ can be constructed.

Once a group is chosen for investigation, we have to assign the quarks and leptons to multiplets (i.e., irreducible representations) of the group. In the earlier chapters, we presented empirical evidence for distinct families (or generations) of fermions, (u,d; $\left.\nu_e, \mathrm{e}\right),\left(\mathrm{c}, \mathrm{s} ; \nu_\mu, \mu\right), \ldots$, where in the first family, for instance, we have
$$
\begin{aligned}
& \left.\left(\begin{array}{l}
\mathrm{u} \\
\mathrm{d}
\end{array}\right)_L, \mathrm{u}_R, \mathrm{~d}_R\right\} \quad \text { each with three colors, } \\
& \left(\begin{array}{c}
\nu_e \\
\mathrm{e}^{-}
\end{array}\right)_L, \mathrm{e}_R^{-},
\end{aligned}
$$
together with their antiparticles. This grouping ensures that we can construct gauge theories free of anomalies, see Section 12.12 . In a family, there are thus 15 left-handed states, for example, those in (15.61) together with $\overline{\mathrm{u}}_L, \overline{\mathrm{d}}_L$, and $\mathrm{e}_L^{+}$. For the $S U(5)$ model, these can be accommodated in a fundamental $\overline{5}$ - and a 10-representation (the 10 is the antisymmetric part of the product of two fundamental 5-representations, compare (2.58)). Explicitly, we have for the lefthanded states,
$$
\begin{aligned}
\overline{5} & =(1,2)+(\overline{3}, 1)=\left(\nu_e, \mathrm{e}^{-}\right)_L+\overline{\mathrm{d}}_L, \\
10 & =(1,1)+(\overline{3}, 1)+(3,2)=\mathrm{e}_L^{+}+\overline{\mathrm{u}}_L+(\mathrm{u}, \mathrm{d})_L,
\end{aligned}
$$
where we have shown the $\left(S U(3)_{\text {color }}, S U(2)_L\right)$ decomposition of the multiplets.
What are the gauge bosons of $S U(5)$ ? An $S U(N)$ gauge theory has $N^2-1$ gauge bosons. For the $S U(5)$ model, these are
$$
24=(8,1)+\underbrace{(1,3)+(1,1)}_{\text {gluons }}+\underbrace{(3,2)+(\overline{3}, 2)}_{\mathrm{X}, \mathrm{Y}, \mathrm{Y} \text { bosens }}
$$

So, we have a new pair of superheavy gauge bosons, $\mathrm{X}$ and $\mathrm{Y}$. They form a weak doublet and are colored. They mediate interactions which turn quarks into leptons:
$$
(\mathrm{u}, \mathrm{d})_L \rightarrow \mathrm{e}_L^{+}+(\overline{\mathrm{Y}}, \overline{\mathrm{X}}),
$$
or, in $S U(5)$ parlance,
$$
(3,2) \rightarrow(1,1) \otimes(3,2) .
$$

Is the appearance of such transitions really surprising? First, recall that at energies above $M_W$, the distinction between weak and electromagnetic interactions disappears. Similarly, at the GUT-scale $M_{X, \gamma}$, which we identify with (15.58), the strong color force merges with the electroweak force, and the sharp separation of particles into colored quarks and colorless leptons, which interact only through the electroweak force, disappears. This leads to lepton/baryon number-violating interactions such as (15.65).

Check back soon!
00:55

Problem 8

What are the charges of the superheavy bosons X and $\mathrm{Y}$ ?

Ashley King
Ashley King
Numerade Educator
02:42

Problem 9

Comment on the behavior of $g_G(Q)$ for $Q>M_X$, see Fig. 15.4.

Sara Ross
Sara Ross
Numerade Educator
