A First Course in Continuum Mechanics

Oscar Gonzalez, Andrew M. Stuart

Chapter 8

Thermal Fluid Mechanics - all with Video Answers

Educators


Chapter Questions

02:06

Problem 1

Consider a body of perfect gas occupying a fixed region $D$ so that $B_{t}=D$ for all $t \geq 0$. Assume there is no body force or heat supply, and define the total energy of the gas by
$$
E(t)=\int_{B_{t}} \frac{1}{2} \rho|\boldsymbol{v}|^{2}+\rho \phi d V_{\boldsymbol{x}}
$$
Show that this total energy is conserved in any smooth motion satisfying $\boldsymbol{v} \cdot \boldsymbol{n}=0$ on $\partial B_{t}$, that is
$$
\frac{d}{d t} E(t)=0
$$

Mukesh Devi
Mukesh Devi
Numerade Educator
02:07

Problem 2

Consider a perfect gas with caloric response functions $\bar{\phi}(\rho, \eta, \boldsymbol{x})$, $\bar{\theta}(\rho, \eta, \boldsymbol{x})$ and $\bar{p}(\rho, \eta, \boldsymbol{x}) .$ Show that the axiom of material frameindifference is satisfied if and only if these functions are independent of $\boldsymbol{x}$

AP
Andreas Papavassiliou
Numerade Educator
06:10

Problem 3

Consider a perfect gas with thermal state equations $p=\widehat{p}(\rho, \theta)$, $\phi=\widehat{\phi}(\rho, \theta)$ and $\eta=\widehat{\eta}(\rho, \theta)$. Show that the Clausius-Duhem inequality holds if and only if $\widehat{p}, \widehat{\phi}$ and $\widehat{\eta}$ satisfy
$$
\frac{\partial \widehat{\eta}}{\partial \theta}=\frac{1}{\theta} \frac{\partial \widehat{\phi}}{\partial \theta}, \quad \widehat{p}=\rho^{2} \frac{\partial \widehat{\phi}}{\partial \rho}-\rho^{2} \theta \frac{\partial \widehat{\eta}}{\partial \rho}
$$

Gaurav Gupta
Gaurav Gupta
Numerade Educator
01:03

Problem 4

Consider a body of perfect gas in smooth, steady, isentropic motion with body force $\boldsymbol{b}=\mathbf{0}$, heat supply $r=0$, density $\rho(\boldsymbol{x})$, velocity $\boldsymbol{v}(\boldsymbol{x})$, and entropy $\eta_{0}$ (constant). Let $\boldsymbol{y}(s), s \in \mathbb{R}$, denote an arbitrary streamline defined by the equation $\boldsymbol{y}(s)^{\prime}=$ $\boldsymbol{v}(\boldsymbol{y}(s))$, and let $\vartheta(s)=|\boldsymbol{v}(\boldsymbol{y}(s))|$ denote the local flow speed and $m(s)=\rho(\boldsymbol{y}(s)) \vartheta(s)$ the local mass flux along the streamline.
(a) For any streamline show
$$
\frac{d \rho}{d s}=\nabla^{x} \rho \cdot \boldsymbol{v}, \quad \vartheta \frac{d \vartheta}{d s}=\boldsymbol{v} \cdot\left(\nabla^{x} \boldsymbol{v}\right) \boldsymbol{v}
$$
(b) Use balance of linear momentum to show
$$
\frac{d \rho}{d s}=-\frac{\rho \vartheta}{c^{2}} \frac{d \vartheta}{d s}, \quad \frac{d m}{d s}=\rho\left[1-M^{2}\right] \frac{d \vartheta}{d s}
$$
where $c(s)$ is the local sound speed and $M(s)$ is the local Mach number along the streamline.

Remark: The first result in (b) shows that mass density always decreases with increasing flow speed. The second result shows that mass flux may increase or decrease depending on the local Mach number. In subsonic regions of a flow $(M<1)$, mass flux increases with increasing flow speed. However, in supersonic regions of flow $(M>1)$, mass flux decreases with increasing flow speed. Many phenomena in the dynamics of perfect gases can be attributed to this change in behavior of the mass flux between subsonic and supersonic speeds.

Manik Pulyani
Manik Pulyani
Numerade Educator
