Computer Graphics with Open GL

Donald Hearn. M. Pauline. Baker, Warren R.Carithers

Chapter 22

Visualization of Data Sets - all with Video Answers

Educators


Chapter Questions

02:49

Problem 1

Write a routine to visulize a two-dimensional scalar data set using a pseudo-color representation.

Anthony Ramos
Anthony Ramos
Numerade Educator
00:36

Problem 2

Write a routine to visualize a two-dimensional scalar data set using contour lines.

ag
Alan Ghazarians
Numerade Educator
00:52

Problem 3

Write a routine to visualize a two-dimensional vector data set using an arrow representation for the vector values. Use a fixed-size arrow with different color codings.

AG
Ankit Gupta
Numerade Educator
01:30

Problem 4

Write a routine to visualize a three-dimensional scalar data set using isosurfaces.

Carson Merrill
Carson Merrill
Numerade Educator
01:38

Problem 5

Write a routine to visualize a three-dimensiona scalar data set using volume rendering. Provide the ability to choose between displaying the max imum, minimum, and average value of the voxels intersected along a given rav.

Robert Leedy
Robert Leedy
Numerade Educator
01:26

Problem 6

Write a routine to visualize a three-dimensional vector data set using an arrow representation that allows the view of a two-dimensional crosssection of data specified by the user. Use color coded arrows to indicate vector magnitude.

Harshita Goel
Harshita Goel
Numerade Educator
04:24

Problem 7

Find a moderately sized data set of interest to you on the internet that contains two-dimensional scalar data. Using the routines developed in the previous exercises, visualize the data using a pseudo-color representation and again using a contour line representation. Compare the two visualizations and list the advantages and disadvantages of displaying the data in each format.

James Kiss
James Kiss
Numerade Educator
02:15

Problem 8

Find a moderately sized data set of interest to you on the internet that contains three-dimensional scalar data. Using the routines developed in the previous exercises, visualize the data using isosurfaces and again using volume rendering. Compare the two visualizations and list the advantages and disadvantages of displaying the data in each format. Also explore the different possible schemes for dealing with multiple voxel intersections in volume rendering (e.g., valueaveraging, min-max values).

James Kiss
James Kiss
Numerade Educator
00:52

Problem 9

Find a moderately sized data set of interest to you on the Internet that contains two-dimensional vector data. Using the routine developed in a previous exercise, visualize the data using an arrow representation for the vector values. Explore the difference between using color-coded arrows to indicate vector magnitude and using arrow size.
