Electricity 1: Devices, Circuits and Materials

Thomas Kubala

Chapter 18

WIRING MATERIALS - all with Video Answers

Educators

Chapter Questions

00:38

Problem 1

List five standard materials used in wiring.
a. __________
b. __________
c. __________
d. __________
e. __________

Ben Nicholson
Ben Nicholson
Numerade Educator

Problem 2

State five places where nonmetallic-sheathed cable cannot be used.
a. __________
b. __________
c. __________
d. __________
e. __________

Check back soon!

Problem 3

List five locations where armored cable cannot be used.

Check back soon!

Problem 4

State the difference between flexible armored cable and flexible metal conduit. __________

Check back soon!

Problem 5

List two applications of flexible metal conduit.
a. __________
b. __________

Check back soon!

Problem 6

State two applications where ENT may not be used.
a. __________
b. __________

Check back soon!

Problem 7

List two advantages of rigid nonmetallic tubing over metallic tubing.
a. __________
b. __________

Check back soon!

Problem 8

A piece of armored cable measures $3 / 4$ inch in diameter. Determine the minimum radius to which this cable may be bent.
a. __________
b. __________

Check back soon!

Problem 9

Explain why rigid galvanized conduit can be used in practically any wiring application.
a. __________
b. __________

Check back soon!
03:00

Problem 10

What is the principal use of surface metal raceway?
__________

Jennifer Stoner
Jennifer Stoner
Numerade Educator

Problem 11

What is the primary type of project in which flat conductor cable is used?
__________

Check back soon!

Problem 12

State two advantages of rigid aluminum conduit as compared to rigid galvanized conduit of the same size.
a. __________
b. __________

Check back soon!

Problem 13

In items 13 through 21, Select the best answer to complete each statement, and place the letter of your answer in the space provided.
The advantage of EMT over rigid conduit (same size) is that it. __________
a. is stronger.
b. is lighter.
c. has a larger external diameter.
d. resists mechanical damage better.
e. resists the corrosive action of water better.

Check back soon!

Problem 14

Select the best answer to complete each statement, and place the letter of your answer in the space provided.
Conduit fittings are used for__________
a. flexible armored cable.
b. surface metal raceway.
c. EMT.
d. nonmetallic cable.
e. rigid metal conduit.

Check back soon!

Problem 15

Select the best answer to complete each statement, and place the letter of your answer in the space provided.
An antishort bushing is used on __________
a. armored cable.
b. surface metal raceway.
c. EMT.
d. nonmetallic cable.
e. rigid metal conduit.

Check back soon!

Problem 16

Select the best answer to complete each statement, and place the letter of your answer in the space provided.
The maximum distance from a box that nonmetallic-sheathed cable shall be stapled will not exceed
a. $1 / 2 \mathrm{ft}$.
d. five times the diameter.
b. $1 \mathrm{ft}$.
e. $4-1 / 2 \mathrm{ft}$.
c. $2 \mathrm{ft}$.

Check back soon!

Problem 17

Select the best answer to complete each statement, and place the letter of your answer in the space provided.
For a given set of electrical installation requirements, the least expensive material to use is
a. surface metal raceway.
d. armored cable.
b. thinwall conduit.
e. flexible metal conduit.
c. nonmetallic-sheathed cable.

Check back soon!

Problem 18

Select the best answer to complete each statement, and place the letter of your answer in the space provided.
The size of rigid metal conduit is determined by the
a. inside diameter.
b. outside diameter.
c. the radius of the bend that can be made.
d. style of pipe.
e. type of coating.

Check back soon!

Problem 19

Select the best answer to complete each statement, and place the letter of your answer in the space provided.
ENT may be used in place of
a. flexible metal conduit.
b. surface metal raceway.
c. rigid metal conduit.
d. thinwall conduit.
e. flat conductor cable.

Check back soon!

Problem 20

Select the best answer to complete each statement, and place the letter of your answer in the space provided.
Rigid nonmetallic conduit may not be
a. buried.
b. impact resistant.
c. encased in concrete.
d. used to support fixtures.
e. purchased with an extra-heavy wall.

Check back soon!

Problem 21

Select the best answer to complete each statement, and place the letter of your answer in the space provided.
Flat conductor cable may be used in
a. homes.
b. hospitals.
c. offices.
d. schools.
e. wet locations.

Check back soon!
