A $1.00 \mathrm{mH}$ inductor and a $1.00 \mathrm{mF}$ capacitor are connected in series. The current in the circuit is described by $I=20.0 t$, where $t$ is in seconds and $I$ is in amperes. Initially, the capacitor has no charge. Determine a. the voltage across the inductor as a function of time, $\mathbf{h}$ the voltage across the capacitor as a function of time, c. the time when the energy stored in the capacitor first exceeds that in the inductor.

A $1.00 \mathrm{mH}$ inductor and a $1.00 \mathrm{mF}$ capacitor are connected in series. The current in the circuit is described by $I=20.0 t$, where $t$ is in seconds and $I$ is in amperes. Initially, the capacitor has no charge. Determine
a. the voltage across the inductor as a function of time, $\mathbf{h}$ the voltage across the capacitor as a function of time,
c. the time when the energy stored in the capacitor first exceeds that in the inductor.

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Inductor Voltage

The voltage across an inductor is determined by how quickly the current through it changes. This relationship is given by the formula V = L (dI/dt), where L is the inductance and dI/dt is the derivative of the current with respect to time. This concept is essential for understanding transient behavior in circuits that include inductors.

Capacitor Voltage

The voltage across a capacitor is related to the charge stored on it. Since current is the rate of change of charge, the capacitor voltage can be found by integrating the current over time and dividing by the capacitance, as given by V = (1/C) ? i dt (with appropriate initial conditions). This relationship underpins the analysis of capacitive charging and discharging processes.

Energy Storage in Reactive Components

Both inductors and capacitors store energy in their respective fields. The energy stored in an inductor is expressed as (1/2)L I^2, while the energy stored in a capacitor is given by (1/2)C V^2. Comparing these energies is crucial in circuit analysis, especially in LC circuits, where energy oscillates between the magnetic field of the inductor and the electric field of the capacitor.
