A 1.80-cm -high object is placed 20.0 cm in front of a concave mirror with a 5.00-cm focal lengt

step 1 Okay, for this problem with a concave mirror, we have an object at a height of 1 .8 centimeters

A 1.80-cm -high object is placed 20.0 cm in front of a...

A $1.80-\mathrm{cm}$ -high object is placed $20.0 \mathrm{cm}$ in front of a concave mirror with a $5.00-\mathrm{cm}$ focal length. What is the position of the image? Draw a ray diagram to illustrate.

Key Concepts

Mirror Equation

The mirror equation relates the object distance (do), the image distance (di), and the focal length (f) through the formula 1/f = 1/do + 1/di. It is a fundamental tool in geometrical optics for determining where an image will form relative to a mirror. This equation applies to both concave and convex mirrors with appropriate sign conventions, making it essential for calculating image positions in curved mirror systems.

Sign Conventions

Sign conventions are a set of rules used in optics to assign positive or negative values to distances and focal lengths in mirror and lens equations. For concave mirrors, the focal length is taken as positive, while object distances are usually positive when the object is in front of the mirror. Using consistent sign conventions is key to correctly applying the mirror equation and determining whether an image is real or virtual, and inverted or upright.

Magnification

Magnification in mirror systems describes the ratio of the image height to the object height and is also given by the negative ratio of the image distance to the object distance (m = -di/do). This concept helps determine not only the size but also the orientation of the image. A negative magnification indicates that the image is inverted relative to the object, while a positive magnification means the image is upright.

Ray Diagram Construction

A ray diagram is a visual tool used in optics to trace the paths of rays emanating from an object and to illustrate how these rays are reflected by a mirror to form an image. For concave mirrors, common rays include one parallel to the principal axis that passes through the focal point after reflection, and another passing through the center of curvature which reflects back on itself. Drawing an accurate ray diagram helps reinforce understanding of image location, size, and orientation.
