A 20-kg laboratory experiment is to be mounted to a table...

A $20-\mathrm{kg}$ laboratory experiment is to be mounted to a table that is bolted to the floor in a laboratory. Measurements indicate that due to the operation of a nearby pump that operates at $2000 \mathrm{r} / \mathrm{min}$, the table has a steady-state displacement of $0.25 \mathrm{~mm}$. What is the maximum stiffness of an undamped isolator, placed between the experiment and the table such that the experiment's acceleration amplitude is less than $4 \mathrm{~m} / \mathrm{s}^2$ ?

Key Concepts

Dynamics of Undamped Systems

Undamped systems do not have mechanisms to dissipate energy, which means they can exhibit large dynamic responses, particularly near resonance. In isolation design, understanding the behavior of an undamped system is important because it dictates how the stiffness must be chosen to prevent excessive acceleration when the system is excited by external vibrations.

Natural Frequency and Stiffness

This concept involves the fundamental relationship in a mass?spring system where the natural frequency is given by the square root of the stiffness divided by the mass. It is crucial for understanding how system parameters influence dynamic behavior, such as resonance and the capacity to isolate vibrations.

Forced Vibration Response to Base Excitation

When a system is subject to a displacement at its base, it experiences forced vibrations. The response amplitude of the mass depends on the ratio of the excitation frequency to the natural frequency, as well as the system's stiffness. This understanding is key for predicting how well the mass will be isolated from the imposed base motion.

Vibration Isolation Design with Acceleration Constraints

In vibration isolation, a critical design goal is to limit the transmitted acceleration to a payload or experiment. Engineers achieve this by selecting system parameters, such as stiffness, to ensure that the acceleration resulting from base excitations remains below a predefined threshold. This concept guides the trade-off between reducing displacement transmission and keeping acceleration within acceptable limits.
