A $2.00-\mathrm{kg}$ block is on a plane inclined at $20.0^{\circ}$ with respect to the horizontal. The coefficient of static friction between the block and the plane is $0.600 .$ a) How many forces are acting on the block? b) What is the normal force? c) Is this block moving? Explain.

A $2.00-\mathrm{kg}$ block is on a plane inclined at $20.0^{\circ}$ with respect to the horizontal. The coefficient of static friction between the block and the plane is $0.600 .$
a) How many forces are acting on the block?
b) What is the normal force?
c) Is this block moving? Explain.

Key Concepts

Normal Force

The normal force is the contact force exerted by a surface that acts perpendicular to it. It counteracts the perpendicular component of the gravitational force. In inclined plane problems, the normal force is typically calculated by considering the component of the weight acting perpendicular to the plane, which is essential for determining frictional forces.

Newton's Laws of Motion

Newton’s Laws govern the relationship between the motion of an object and the forces acting on it. In problems involving an inclined plane, these laws (especially the second law, which relates net force to mass and acceleration) help in setting up the equations of equilibrium or motion by considering the combined effects of gravitational, normal, and frictional forces.

Free-Body Diagram

A free-body diagram is a graphical representation used to show all the external forces acting on a body. It is crucial for identifying and analyzing forces such as gravity, normal force, and friction. This visualization aids in correctly decomposing forces and applying Newton’s laws to solve for unknowns in mechanics problems.

Decomposition of Forces on an Inclined Plane

When an object is on an inclined plane, its weight must be resolved into two components: one parallel to the surface, which tends to move the object down the slope, and one perpendicular to the surface, which affects the normal force. This decomposition, using sine and cosine functions, is essential for accurately analyzing the equilibrium or motion of objects on slopes.

Static Friction

Static friction is the force that resists the initiation of motion between two surfaces in contact. It adjusts up to a maximum value, defined by the coefficient of static friction times the normal force, to prevent motion. Understanding static friction is key to determining whether an object on an inclined plane will remain at rest or begin to move.
