A 2.00-kg block (M1) and a 6.00-kg block (M2) are connected by a massless string. Applied forces

step 1 We're asked to think about two blocks. And here's my M2 and M1. So I've got M1, and let's make t

A 2.00-kg block (M1) and a 6.00-kg block (M2) are connected...

A $2.00-\mathrm{kg}$ block $\left(M_{1}\right)$ and a $6.00-\mathrm{kg}$ block $\left(M_{2}\right)$ are connected by a massless string. Applied forces, $F_{1}=10.0 \mathrm{~N}$ and $F_{2}=5.00 \mathrm{~N},$ act on the blocks, as shown in the figure. a) What is the acceleration of the blocks? b) What is the tension in the string? c) What is the net force acting on $M_{1}$ ? (Neglect friction between the blocks and the table.)

A $2.00-\mathrm{kg}$ block $\left(M_{1}\right)$ and a $6.00-\mathrm{kg}$ block $\left(M_{2}\right)$ are connected by a massless string. Applied forces, $F_{1}=10.0 \mathrm{~N}$ and $F_{2}=5.00 \mathrm{~N},$ act on the blocks, as shown in the figure.
a) What is the acceleration of the blocks?
b) What is the tension in the string?
c) What is the net force acting on $M_{1}$ ? (Neglect friction between the blocks and the table.)

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Tension in a Massless String

In problems involving connected objects, the assumption that the string is massless and inextensible implies that the tension is the same throughout its length. This property is key when analyzing forces on individual blocks, as it provides a consistent force value acting between the objects.

System Analysis of Connected Objects

When objects are connected by a string or other constraint, their motions are interdependent. Analyzing the system as a whole allows the determination of a common acceleration and simplifies the problem by reducing it to a single system-level equation, which then facilitates finding individual forces such as tension.

Free-Body Diagrams

Free-body diagrams are visual representations used to isolate a single object and depict all the forces acting upon it. They are crucial for identifying applied forces, friction, tension, and other interactions, and for setting up the equations required to solve for unknowns like acceleration and tension.

Newton's Second Law

Newton's Second Law of Motion states that the net force acting on an object is equal to the mass of the object multiplied by its acceleration. This law is fundamental in dynamics and is used to set up equations that relate the forces acting on each object (or on a system as a whole) to its acceleration.

Transcript

00:01 We're asked to think about two blocks.

00:04 And here's my m2 and m1.

00:13 So i've got m1, and let's make this m2, make this m1.

00:22 I've got force 2, and here's my t, here's my t, and my f1, and this is my positive y, and this is my positive y, is my positive x.

00:51 So let's draw for, whoopsie, hang on a second here.

01:30 I'm going to do my free body diagrams next.

01:39 And just thinking about this before i start drawing them.

01:49 Okay, so let's do m2.

01:57 And i've got f2 and t.

02:05 M1.

02:09 I have f1 and t.

02:21 Okay and then my composite since t's are equal will be two and f one okay so we're going to think about new the second law here and that'll equal m times a x then look at this or m1 plus m2 equals our mass and then we'll have f1 plus f2 equals our mass and then we'll have f1 plus f f2 equals m1 plus m2 times acceleration.

03:23 So then we can consider a will equal f1 plus f2 over m1 plus m2.

03:38 Substitute our values in here.

03:43 They were 10 newtons and 5 newtons.

03:47 I don't remember which was which.

03:49 So and my masses were two and six.

04:00 And that would equal 1 .875 meters per second squared...
