A baseball attachment that helps people with mobility impairments play T-ball and baseball is powered by a spring that is unstretched at position $2 .$ The spring is attached to a cord that is fastened to point $B$ on the 75 -mm-radius pulley. The pulley is fixed at point $O,$ rotates backward to the cocked position at $\theta=120^{\circ},$ and the rope wraps around the pulley and stretches the spring with a stiffness of $k=2000 \mathrm{N} / \mathrm{m}$. The combined mass moment of inertia of all the rotating components about point $O$ is $0.40 \mathrm{kg} \cdot \mathrm{m}^{2} .$ The swing is timed perfectly to strike a 145 -gram baseball traveling with a speed of $v_{0}=10 \mathrm{m} / \mathrm{s}$ at a distance of $h=0.7 \mathrm{m}$ away from point $O$ Knowing that the coefficient of restitution between the bat and ball is 0.59 , determine the velocity of the baseball immediately after the impact. Assume that the ball is traveling primarily in the horizontal plane and that its spin is negligible.

Key Concepts

Spring Mechanics

This concept involves understanding how springs behave when they are deformed. Hooke’s law, which states that the force exerted by a spring is proportional to its displacement from its natural (unstretched) length, is crucial. In problems like this, the spring stores potential energy when it is stretched, and this energy can be converted to kinetic energy that contributes to the motion of other parts of the system.

Rotational Dynamics

Rotational dynamics is the branch of mechanics that deals with the motion of bodies rotating about an axis. Key elements include the moment of inertia, which quantifies an object's resistance to changes in its rotational motion, and the relation between angular velocity and linear velocity. In this problem, the bat’s motion involves rotation about a pivot point, and the energy stored in the spring helps overcome the rotational inertia to produce a swing.

Collision Dynamics and Impulse

This concept deals with analyzing forces and momentum changes during collisions, which are typically very brief, high-force events. In the context of impacts such as a bat striking a ball, the impulse (force applied over a short time interval) results in sudden changes in momentum. Understanding how the momentum is transferred between the rotating bat and the ball is critical to predicting post-impact velocities.

Coefficient of Restitution

The coefficient of restitution is a dimensionless parameter that characterizes the elasticity of a collision. It defines the ratio of relative speeds after and before an impact. A value less than one indicates a partially inelastic collision, meaning some energy is lost to sound, heat, or deformation. This concept is essential in problems involving impacts, such as predicting the ball’s velocity after striking a bat, by relating the speeds of approach and separation.
