A beam of energetic ( $>100 \mathrm{eV}$ ) neutral hydrogen atoms is coming through a hole in the wall of plasma confinement device. Describe the apparatus that you would use to measure the energy distribution of these atoms.
FIGURE CAN'T COPY.

Key Concepts

Neutral Particle Diagnostics

This concept involves the methods and instruments used to detect and measure neutral atoms, which do not inherently respond to electric or magnetic fields. Since neutrals cannot be manipulated directly using conventional charged-particle techniques, specialized diagnostic tools are employed to first convert them into detectable charged species.

Ionization Mechanism

An essential step in detecting neutral atoms is to convert them into charged particles. This is typically achieved by employing an ionization technique such as surface ionization or electron impact ionization, where the neutral atoms interact with a material surface or a beam of electrons to acquire a charge. This conversion enables subsequent energy analysis using electromagnetic fields.

Electrostatic Energy Analysis

Once the neutral atoms have been ionized, their energy distribution can be analyzed using electrostatic energy analyzers. These devices, often in the form of retarding field analyzers, apply a variable electric potential barrier. Only ions with kinetic energies exceeding the potential barrier can pass through, thereby allowing the determination of the energy spectrum based on the fraction of ions detected as the voltage is varied.

Detection System

After energy filtering, highly sensitive detectors such as channel electron multipliers or microchannel plates are used to capture the ionized particles. The detection system records the spatial and/or temporal ion count data, which is then processed to reconstruct the energy distribution of the original neutral atom beam.
