A brick wall with thermal conductivity κ=1.3 W /(m ·K) is...

A brick wall with thermal conductivity $\kappa=1.3 \mathrm{W} /(\mathrm{m} \cdot \mathrm{K})$ is covered completely with a sheet of foam of the same thickness as the brick, but with $\kappa=0.025 \mathrm{W} /(\mathrm{m} \cdot \mathrm{K}) .$ How is the rate at which heat is conducted through the wall changed by the addition of the foam?

Key Concepts

Thermal Conduction

This concept refers to the process whereby heat energy is transferred through a material from a region of higher temperature to one of lower temperature. It is governed by the temperature gradient and the intrinsic properties of the material, enabling predictions on how heat flows through different substances.

Thermal Conductivity

Thermal conductivity is a material property that quantifies the ability of a substance to conduct heat. A higher thermal conductivity means the material allows heat to pass through more easily, while a lower thermal conductivity indicates that the substance acts as an insulator, reducing the rate of heat transfer.

Composite Systems and Series Thermal Resistance

In systems where different materials are layered, such as a brick followed by foam, each layer adds its own thermal resistance to the overall heat transfer. The concept of series thermal resistance is used to analyze such setups by summing the individual thermal resistances of each layer, which determines how much the overall rate of heat conduction is reduced.

Heat Transfer Rate Equation

The equation for the rate of heat transfer, often written as Q/t = (?T / R_total), relates the heat flow rate to the temperature difference across a material and the thermal resistance of the system. For composite materials, this equation is adapted by considering the sum of the resistances from each layer, indicating how the overall heat transfer is affected by adding materials with different thermal conductivities.
