A buried insulated power cable has an outside diameter of 3 cm and is 1 m below the surface of

step 1 In this problem, first I am calculating the value of area. We know that area is equal to 4 pi mu

A buried insulated power cable has an outside diameter of 3...

A buried insulated power cable has an outside diameter of $3 \mathrm{~cm}$ and is $1 \mathrm{~m}$ below the surface of the ground. What is the maximum allowable dissipation per unit length if the outer surface of the insulation must not exceed $350 \mathrm{~K}$ when the ground surface and the deep soil are at $300 \mathrm{~K}$ ? Take $k=1 \mathrm{~W} / \mathrm{m} \mathrm{K}$ for the soil.

Key Concepts

Thermal Conduction

Thermal conduction is the process by which heat energy is transferred through a material due to a temperature difference. It is governed by Fourier’s law, which relates the heat flux to the temperature gradient and the thermal conductivity of the material. This concept is essential for analyzing how heat is carried away from a power cable buried in soil.

Thermal Resistance in Cylindrical Systems

Thermal resistance is a measure of a material's resistance to heat flow. In cylindrical systems, such as a buried cable, the geometry influences the resistance to conduction. The concept involves calculating the effective resistance encountered by heat as it moves radially outward from the cable through the surrounding soil.

Heat Dissipation and Energy Balance

Heat dissipation refers to the process of releasing energy in the form of heat from a system. In applications involving buried cables, it is important to determine the amount of power per unit length that can be safely dissipated without raising the temperature of the surrounding material above a certain limit. This involves balancing the generated heat and the conductive removal of that heat.

Boundary Conditions in Heat Transfer

Boundary conditions are constraints that define the temperatures or heat fluxes at the interfaces of a material. In this context, specifying the temperatures at the ground surface and deep soil establishes the limits within which the system must operate. Understanding these conditions is crucial for solving the conduction equation and determining the permissible power dissipation.
