A car is driving on a straight, level road at constant speed. Draw an FBD for the car, showing t

step 1 So we know that the net force on the car is zero because we have the car moving at a constant ve

A car is driving on a straight, level road at constant...

Key Concepts

Normal Force

The normal force is the reactive force provided by the surface, in this case the road, which acts perpendicular to the surface. It balances the gravitational force, ensuring that the car does not accelerate vertically, and is essential for representing the vertical forces on the car in the free-body diagram.

Gravitational Force (Weight)

The gravitational force, or weight, is a force acting on the car due to the Earth’s gravity, directed downwards. It is calculated as the product of the mass of the car and the acceleration due to gravity, and is a key force to include in the free-body diagram.

Resistive Forces (Friction and Drag)

Resistive forces such as friction (from the contact between the tires and the road) and aerodynamic drag (from the air) oppose the forward motion of the car. At constant speed, the driving force generated by the engine is exactly balanced by these resistive forces, resulting in no net horizontal acceleration.

Free-Body Diagram (FBD)

A free-body diagram is a graphical illustration used to visualize all the forces acting on an object. It simplifies the physical situation by representing the object as a point or a simple shape and drawing vectors for each force, thus helping in applying Newton’s laws to analyze equilibrium or motion.

Newton's First Law (Law of Inertia)

Newton's First Law states that an object will remain at rest or move at a constant velocity unless acted upon by a net external force. In the context of the car moving at constant speed, this principle implies that all forces acting on the car must be balanced, meaning the net force is zero.
