A centrifugal pump impeller delivers 4000 gal/min of water at $20^{\circ} \mathrm{C}$ with a shaft rotation rate of $1750 \mathrm{r} / \mathrm{min}$. Neglect losses. If $r_{1}=6$ in, $r_{2}=14$ in, $b_{1}=b_{2}=1.75$ in,$V_{t 1}=10 \mathrm{ft} / \mathrm{s},$ and $V_{t 2}=110 \mathrm{ft} / \mathrm{s},$ compute the absolute velocities $(a) V_{1}$ and $(b) V_{2}$ and $(c)$ the horsepower required. $(d)$ Compare with the ideal horsepower required.

A centrifugal pump impeller delivers 4000 gal/min of water at $20^{\circ} \mathrm{C}$ with a shaft rotation rate of $1750 \mathrm{r} / \mathrm{min}$. Neglect losses. If $r_{1}=6$ in, $r_{2}=14$ in, $b_{1}=b_{2}=1.75$ in,$V_{t 1}=10 \mathrm{ft} / \mathrm{s},$ and $V_{t 2}=110 \mathrm{ft} / \mathrm{s},$ compute the absolute
velocities $(a) V_{1}$ and $(b) V_{2}$ and $(c)$ the horsepower required. $(d)$ Compare with the ideal horsepower required.

Key Concepts

Horsepower and Efficiency Calculations

Calculating the horsepower required by a pump involves assessing the energy rate that must be imparted to the fluid. This includes computing the work done on the fluid based on the energy transfer (from velocity changes) and converting it to power using appropriate unit conversions. Additionally, comparing the computed power with the ideal or theoretical horsepower helps in understanding the efficiency and losses in the pumping system.

Continuity Equation and Flow Rate Conversion

The continuity equation's application ensures that the mass (or volumetric) flow rate remains constant through different sections of the pump. In pump calculations, converting flow rates between different units and relating these flow rates to the cross-sectional areas of the flow passages is vital for determining the corresponding velocities within the pump.

Velocity Triangles

Velocity triangles are fundamental in pump and turbomachinery analysis. They graphically represent the relationship between the absolute velocity of the fluid, the relative velocity as seen in the rotating frame of the impeller, and the blade (or tangential) velocity. This representation is crucial when analyzing and determining the inlet and outlet velocities, ensuring that both the conservation of momentum and energy are properly accounted for in the design and analysis.

Euler's Pump Equation

Euler's equation for pumps is key to quantifying the energy transfer from the impeller to the fluid. It relates the change in the fluid’s tangential velocity component to the head developed by the pump. By considering the difference in the product of the impeller radii and tangential velocities at the inlet and outlet, this equation provides a basis for estimating the theoretical energy imparted to the fluid.

Centrifugal Pump Operation

This concept involves understanding how a centrifugal pump imparts energy to a fluid by converting the rotational energy of the impeller into kinetic energy and pressure energy in the fluid. It encompasses the operation of the impeller, the fluid’s flow through the pump passages, and the conversion process that leads to an increase in fluid head.
