A certain ferrite core is known to have loss of $4 \mathrm{~W}$ in a dc-dc converter application with a switching frequency of $100 \mathrm{kHz}$. If the switching frequency in this same converter doubles, about how much will the power loss change?

Key Concepts

Frequency Dependence of Magnetic Losses

The dependence of magnetic losses on frequency is a fundamental concept in power electronics. As the operating frequency increases, the losses associated with the magnetic core—due to both hysteresis and eddy currents—increase, often in a nonlinear fashion. This principle explains why in high-frequency converters, even a doubling of the switching frequency can lead to a substantial increase in power loss, emphasizing the need for meticulous thermal and efficiency management in system design.

Core Loss in Magnetic Materials

Core losses in magnetic materials primarily consist of hysteresis loss and eddy current loss. Hysteresis loss is generally proportional to the frequency and the material’s magnetic properties, while eddy current loss varies with the square of the frequency. The combined effect of these losses means that as the switching frequency increases, the total core loss rises, requiring careful material selection and design considerations in high-frequency applications.

Steinmetz Equation

The Steinmetz equation is an empirical formula used to estimate the core losses in magnetic materials. It relates the power loss per unit volume to both the frequency and the peak magnetic flux density, typically by a relation of the form P = k * f^? * B^?. This equation highlights that even a modest increase in frequency can result in a significantly higher power loss, which is critical in the design of high-frequency magnetic components.
