A circular loop of wire, with radius $R$, lies in the $x y$ plane, centered at the origin. and carries a current $I$ running counterclockwise as viewed from the positive $z$ axis. (a) What is its magnetic dipole moment? (b) What is the (approximate) magnetic field at points far from the origin? (c) Show that, for points on the $z$ axis, your answer is consistent with the exact field (Ex. 5.6 ). when $z \gg R$

A circular loop of wire, with radius $R$, lies in the $x y$ plane, centered at the origin. and carries a current $I$ running counterclockwise as viewed from the positive $z$ axis.
(a) What is its magnetic dipole moment?
(b) What is the (approximate) magnetic field at points far from the origin?
(c) Show that, for points on the $z$ axis, your answer is consistent with the exact field (Ex. 5.6 ). when $z \gg R$

Key Concepts

Biot–Savart Law

The Biot–Savart law provides the fundamental means of calculating the magnetic field generated by a steady current. It involves integrating contributions from each infinitesimal segment of the current-carrying conductor. In the context of a circular loop, this law underpins the derivation of both the exact field distribution and its dipole approximation, making it an essential tool in the study of magnetic fields generated by current configurations.

Multipole Expansion (Dipole Approximation)

This technique simplifies the description of electromagnetic fields far from their sources by expanding the field in powers of inverse distance. For a small current loop observed at large distances, only the lowest order (dipole) term is significant. This approximation allows one to relate the exact solution in a limited region (for instance, along the symmetry axis) to an idealized field that falls off as 1/r³ and is governed solely by the magnetic dipole moment.

Magnetic Field of a Magnetic Dipole

At distances much larger than the dimensions of the current loop, the magnetic field produced by the loop can be approximated by that of a magnetic dipole. The dipole magnetic field decreases as the inverse cube of the distance from the source. Its spatial dependence is captured by a standard dipole field formula, which involves the magnetic dipole moment, the distance from the dipole, and the direction relative to the dipole axis.

Magnetic Dipole Moment

This concept defines a current loop’s effect in producing a magnetic field. In general, a magnetic dipole moment for a loop is given by the product of the current and the area of the loop, with its direction determined by the right?hand rule. It is a vector quantity that characterizes the strength and orientation of the loop’s magnetic effect, and serves as the primary parameter in describing the behavior of the loop in external magnetic fields.
