A convex lens has focal length $f$ centimeters. If an object is placed a distance $p$ centimeters from the lens, then the distance $q$ centimeters of the image from the lens is related to $p$ and $f$ by the lens equation $$\frac{1}{p}+\frac{1}{q}=\frac{1}{f}$$ As shown in the figure on the following page, $p$ must be greater than $f$ for the rays to converge. (a) Investigate $\lim _{p \rightarrow f^{*}} q$. (b) What is happening to the image as $p \rightarrow f^{+} ?$

A convex lens has focal length $f$ centimeters. If an object is placed a distance $p$ centimeters from the lens, then the distance $q$ centimeters of the image from the lens is related to $p$ and $f$ by the lens equation
$$\frac{1}{p}+\frac{1}{q}=\frac{1}{f}$$
As shown in the figure on the following page, $p$ must be greater than $f$ for the rays to converge.
(a) Investigate $\lim _{p \rightarrow f^{*}} q$.
(b) What is happening to the image as $p \rightarrow f^{+} ?$

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Image Formation at the Focal Point

When an object is placed at the focal length of a convex lens, the refracted rays emerge parallel, meaning they do not converge to form a real image. This situation, characterized by the image distance tending to infinity, illustrates a fundamental boundary condition in image formation, where the lens no longer produces a finite image.

Lens Equation

The lens equation, given by 1/p + 1/q = 1/f, is a core relationship in geometric optics that connects the object distance (p), the image distance (q), and the focal length (f) of a lens. This equation is essential for determining the position and nature of the image formed by a lens.

Limit Analysis in Optics

Limit analysis involves studying the behavior of optical equations as certain parameters approach critical values. In this context, examining the limit as the object distance p approaches the focal length f helps us understand the asymptotic behavior of the image distance (q) and predict the physical outcome in the lens system.
