A current pulse is fed to the partial circuit shown in...

A current pulse is fed to the partial circuit shown in Figure P32.25. The current begins at zero, then becomes 10.0 $\mathrm{A}$ between $t=0$ and $t=200 \mu \mathrm{s},$ and then is zero once again. Determine the current in the inductor as a function of time.

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Inductor Transient Response

This concept involves understanding how an inductor reacts when there is a sudden change in the circuit conditions, such as the application or removal of a current pulse. An inductor opposes instantaneous changes in current, and its response is described by differential equations that incorporate its stored magnetic energy. This behavior is crucial in predicting how the current in the inductor evolves over time in transient events.

Time Constant

The time constant, typically denoted as ?, determines the rate at which the circuit responds to changes. In circuits involving inductors, particularly in RL circuits, the time constant is defined as the ratio of the inductance to the resistance (? = L/R). It characterizes the exponential rate at which the current approaches its new steady-state value following a change.

Initial Conditions and Continuity of Inductor Current

In any analysis of transient circuits, it is important to note that the current through an inductor cannot change instantaneously due to its inherent energy storage in the magnetic field. This principle imposes initial condition constraints, meaning that the current value just before a switching event must be equal to the value just after. This property is key to correctly applying boundary values and solving the transient response equations.
