A cylindrical specimen of some metal alloy 10 mm(0.4 in. ) in diameter is stressed elastically

step 1 Calculating the area first. So area is equal to pi by 4 d knot square here which is equal to pi

A cylindrical specimen of some metal alloy 10 mm(0.4 in. )...

A cylindrical specimen of some metal alloy $10 \mathrm{mm}(0.4 \text { in. })$ in diameter is stressed elastically in tension. A force of $15,000 \mathrm{N}\left(3370 \mathrm{lb}_{\mathrm{f}}\right)$ produces a reduction in specimen diameter of $7 \times 10^{-3} \mathrm{mm}\left(2.8 \times 10^{-4} \text {in. }\right)$ . Compute Poisson's ratio for this material if its elastic modulus is $100 \mathrm{GPa}\left(14.5 \times 10^{6} \mathrm{psi}\right)$.

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Stress and Strain

Stress is the applied force per unit area on a material, while strain is the measure of deformation experienced by the material as a result. The linear relationship between stress and strain in the elastic regime is the fundamental basis for understanding material behavior under load.

Hooke's Law (Linear Elasticity)

Hooke's Law states that, within the elastic limit, the strain in a material is directly proportional to the applied stress. This principle underpins the relationship between applied loads and the resulting strains, allowing the elastic modulus and Poisson's ratio to be used in predicting deformation behavior.

Elastic Modulus

Elastic modulus, or Young's modulus, is a measure of a material's stiffness. It represents the ratio of applied uniaxial stress to the resulting axial strain within the elastic limit of the material, and it is used to predict how much a material will deform under a given load.

Poisson's Ratio

Poisson's ratio is a dimensionless measure that quantifies the ratio of lateral (transverse) strain to axial (longitudinal) strain in a material subjected to uniaxial stress. It provides insight into the extent of lateral contraction (or expansion) relative to axial elongation when the material is loaded.
