A ferromagnetic material has a remanence of 1.0 tesla and a...

A ferromagnetic material has a remanence of 1.0 tesla and a coercivity of $15,000 \mathrm{A} / \mathrm{m}$ Saturation is achieved at a magnetic field strength of $25,000 \mathrm{A} / \mathrm{m},$ at which the flux density is 1.25 teslas. Using these data, sketch the entire hysteresis curve in the range $H=-25,000$ to $+25,000 \mathrm{A} / \mathrm{m} .$ Be sure to scale and label both coordinate axes.

Key Concepts

Saturation Magnetization

Saturation magnetization is the maximum magnetization that a ferromagnetic material can achieve under an external magnetic field. Beyond this point, further increases in the applied field result in minimal changes in magnetization.

Scaling and Labeling Graph Axes

Proper scaling and labeling of graph axes are essential when plotting physical data such as a hysteresis curve. This ensures that the range and units of both the applied magnetic field (H) and the magnetic flux density (B) are accurately represented, allowing for clear and precise visualization of the material’s magnetic behavior.

Coercivity

Coercivity is the measure of the intensity of the reverse applied magnetic field required to reduce the magnetization of a ferromagnetic material to zero. It reflects the resistance of the material to becoming demagnetized.

Hysteresis Curve

The hysteresis curve is a graph plotting the relationship between magnetic field strength (H) and magnetic flux density (B) for a ferromagnetic material. It demonstrates the lag between the applied magnetic field and the resulting magnetization, highlighting key phenomena such as remanence and coercivity.

Ferromagnetism

Ferromagnetism is a property of certain materials, such as iron, that exhibit strong magnetic behavior due to the parallel alignment of atomic moments. This leads to a pronounced magnetic response that can be retained even after an external magnetic field is removed.

Remanence

Remanence refers to the residual magnetization that remains in a ferromagnetic material after the external magnetic field has been removed. It indicates the ability of the material to retain magnetic properties in the absence of an applied field.
