(a) For z=f(x, y)=x y, sketch and label the level curves z=±1, z=±2 (b) Sketch and label cross-s

(a) For z=f(x, y)=x y, sketch and label the level curves...

Key Concepts

Intersection of Surfaces and Planes

The intersection of a surface with a plane results in a curve that represents common solutions to both equations. This concept is useful for exploring how a surface behaves when cut by a particular plane, and it provides insight into the geometry of the surface.

Level Curves

Level curves are the sets of points in the domain of a function of two variables where the function takes on a constant value. They provide a two-dimensional view of the function's behavior and help one visualize how the output changes over the domain, similar to contour lines on a map.

Cross-Sections

Cross-sections are curves obtained by intersecting a surface with a plane, typically by fixing one of the variables. This method helps to analyze the behavior of a function along specific directions, revealing geometric shapes and properties of the surface in slices.

Surface Graphs of Multivariable Functions

The graph of a function of two variables is a surface in three-dimensional space representing points (x, y, f(x, y)). Understanding these surfaces is key in multivariable calculus, as it allows one to visualize how the function behaves in the entire domain.

Transcript

0:00 Hello there.

00:01 For this exercise we have the following function that is equal to x times y.

00:07 And we need to plot for this, we need to sketch the level curves for the surface.

00:16 So here on the right you can find the corresponding level curves for each value of z.

00:25 We need to take for plus and minus one and then for plus and minus two.

00:29 So here you find for this, it corresponds the value of z equals to 2 to minus 1.

00:41 The yellow dashed line corresponds to the values of z equals to 1.

00:51 And the red curbs are for values of z equals to minus 2.

00:58 And finally, this purple dashed line corresponds for values of z equals to 2.

01:05 One important thing to remark about these level of curves is that you can observe that in this diagonal is located these hyperboloids that uh this epiparvolous that constructed this surface and in a similar way you obtained that for negative values of z we have uh hyperbolas in this direction okay so uh that's this is the geometric part, but of course in order to show this, you need to consider what happened with the function itself.

01:42 So you need to just give some values for z and you can observe that for z equals to plus minus one.

01:50 The function that we are defining is x times y equals to plus minus one.

01:56 And for z equals to plus minus two, then as directly we have the following equation, that is x times y equals to plus minus two.

02:08 Now let me show you what is the meaning of these curves if we see the full plot in three dimensions.

02:17 Okay so here we have the function this blue curve blue surface to be more precise corresponds to the equation that we are considered and this plane in yellow corresponds to the intersection with the specific value of z.

02:34 So at this point the value of z that is taking is near zero okay and actually when this is equal to zero what you observe is just these lines that cross okay so the intersection of this plane with the surface is what is going to define the level curves that we're constantly that you can observe that if we start to decrease the value of z then we're forming this hypervolus in this part of the plot similarly we start to increase then we're considering the hyperbolas in the other diagonal.

03:11 Okay, so that is more or less the graphical representation of these level curves but in three dimensions...
