A GaAs pn junction at T=300 K has impurity doping concentrations of Na=2 ×10^16 cm^-3 and Nd=5

step 1 In this question we have to find VR2 from given information and from the given data V -by is 1 .

A GaAs pn junction at T=300 K has impurity doping...

A GaAs pn junction at $T=300 \mathrm{~K}$ has impurity doping concentrations of $N_{a}=2 \times 10^{16}$ $\mathrm{cm}^{-3}$ and $N_{d}=5 \times 10^{15} \mathrm{~cm}^{-3} .$ It is determined that the ratio of junction capacitance at two reverse-biased voltages is $C_{j}^{\prime}\left(V_{R 1}\right) / C_{j}^{\prime}\left(V_{R 2}\right)=1.5$, where $V_{R 1}=0.5 \mathrm{~V}$. Determine $V_{R 2}$.

Key Concepts

Capacitance-Voltage (C-V) Analysis

Capacitance-voltage analysis is a technique used to study the electrical properties of semiconductor junctions. By measuring the capacitance at different reverse bias voltages, one can derive important parameters such as the doping concentrations, built-in potential, and the grading of the junction, which are crucial for device characterization and design.

Junction Capacitance and Voltage Dependence

Junction capacitance in a reverse-biased pn junction arises from the ability of the depletion region to store charge. It is inversely related to the width of the depletion region, and therefore depends on the applied reverse bias voltage. Understanding this voltage dependence is essential for using capacitance-voltage measurements to extract device parameters and doping profiles.

Impurity Doping in Semiconductors

Impurity doping introduces donor or acceptor atoms into a semiconductor to modify its electrical properties. The relative concentrations of these dopants determine the majority carriers, affect the width of the depletion region, and play a critical role in defining the behavior of devices like diodes.

pn Junction

A pn junction is formed by joining p-type and n-type semiconductors, creating a depletion region at the interface where mobile charge carriers are absent. This region supports an internal electric field that influences carrier movement and device behavior under various biasing conditions.

Reverse Bias and Depletion Region

Under reverse bias conditions, the applied voltage widens the depletion region by pulling charge carriers away from the junction. This increase in the depletion width reduces the junction capacitance and is a fundamental characteristic used to analyze and design semiconductor devices.
