A gas flows along the $x$ axis with a speed of $V=5 x \mathrm{m} / \mathrm{s}$ and eressure of $p=10 x^{2} \mathrm{N} / \mathrm{m}^{2},$ where $x$ is in meters. (a) Determine the time rate of change of pressure at the fixed location $x=1$ (b) Determine the time rate of change of pressure for a fluid particle flowing past $x=1 .$ (c) Explain without using any equations why the answers to parts (a) and (b) are different.

A gas flows along the $x$ axis with a speed of $V=5 x \mathrm{m} / \mathrm{s}$ and
eressure of $p=10 x^{2} \mathrm{N} / \mathrm{m}^{2},$ where $x$ is in meters.
(a) Determine the time rate of change of pressure at the fixed location $x=1$
(b) Determine the time rate of change of pressure for a fluid particle flowing past $x=1 .$ (c) Explain without using any equations why the answers to parts (a) and (b) are different.

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Eulerian Description

This concept refers to analyzing fluid properties (like pressure or velocity) at fixed spatial locations as a function of time. In this description, observers are stationed at specific points in space and measure how fluid variables change while the fluid flows past them.

Lagrangian Description

In contrast, the Lagrangian description focuses on following individual fluid particles as they move along their trajectories. Observers moving with the particles record changes in the properties that these specific fluid elements experience over time.

Material Derivative

The material derivative is a key mathematical tool that bridges the Eulerian and Lagrangian descriptions. It combines the local time derivative of a property at a fixed spatial location with a convective term that accounts for the change due to the motion of the fluid particle, thus providing the overall rate of change of that property following the particle.

Convective Effect

This refers to the influence of fluid motion on the rate of change experienced by a moving particle. It arises because a fluid particle moving through a spatially varying field (such as pressure) encounters different values along its path, which must be included together with the local time change to determine the total rate of change experienced by the particle.
