A jack uses a double-thread ACME thread with a major diameter of 25 mm and a pitch of 5 mm . The jack is intended to lift 4000 N. Determine
the lead angle,
whether the jack is self-locking,
the torque to raise the load,
the torque to lower the load, and
the efficiency of the jack.

Key Concepts

Efficiency of Screw Jacks

Efficiency in screw jacks is defined as the ratio of useful work output (lifting a load) to the work input (the applied rotational energy). It is influenced by the geometry of the screw (specifically the lead angle) and by friction in the threads. Higher friction or a smaller lead angle generally decreases the efficiency while improving self-locking capability.

Lead Angle

The lead angle is the angle between the helix of the thread and a plane perpendicular to the screw’s axis. It is determined by the relationship between the thread’s lead (which is the linear distance advanced per turn) and the circumference of the screw. A larger lead angle typically implies that the screw is more efficient at transferring rotational motion into linear motion but can be less self-locking.

Self-Locking Mechanism

Self-locking refers to a property of screw threads whereby the load cannot drive the screw in reverse, due to friction and geometry (often a small lead angle). This characteristic is crucial in preventing the screw from unwinding under the applied load when the driving force is removed.

Torque Calculations for Screw Threads

Calculating the torque required to move a load using a screw involves determining the moment needed to overcome both the load’s resistance and friction. The required torque differs when raising versus lowering the load because frictional forces work in opposite directions. This analysis uses the screw’s geometry, including the lead or pitch and the diameter, to relate the applied torque to the linear force on the load.
