A jet-engine noise suppressor consists of a movable duct which is secured directly behind the jet exhaust by cable $A$ and deflects the blast directly upward. During a ground test, the engine sucks in air at the rate of $43 \mathrm{kg} / \mathrm{s}$ and burns fuel at the rate of $0.8 \mathrm{kg} / \mathrm{s} .$ The exhaust velocity is $720 \mathrm{m} / \mathrm{s}$. Determine the tension $T$ in the cable.

Key Concepts

Momentum Conservation

This principle states that in the absence of external forces, the total momentum of a system remains constant. In the context of jet engines, it means that the momentum carried away by the exhaust must be balanced by an equal and opposite force on the engine, which in turn is transferred to any supporting structure such as a cable.

Mass Flow Rate

Mass flow rate is the quantity of mass passing through a given cross-sectional area per unit time. In jet engine calculations, it is crucial because the momentum change—and hence the force produced—is determined by the product of the mass flow rate and the velocity of the exhaust gases.

Newton's Second Law

Newton's Second Law relates the net force acting on an object to the rate of change of its momentum. In jet propulsion, the net force (or thrust) produced by the engine can be calculated as the mass flow rate multiplied by the exhaust velocity. This law provides the framework for analyzing how the expelled mass translates into a propulsive force.

Thrust

Thrust is the force generated by the jet engine as it expels mass at high velocity. It is directly calculated using the mass flow rate and the exhaust velocity, and it must be counterbalanced by supports like the tension in the cable during tests. Understanding thrust is essential in determining the resulting forces on structural components in propulsion systems.
