A large window measures $2.0 \mathrm{~m}$ by $3.0 \mathrm{~m}$. At what rate will heat be conducted through the window when the room temperature is $20^{\circ} \mathrm{C}$ and the outside temperature is $0^{\circ} \mathrm{C}$ if (a) the window consists of a single pane of glass $4.0 \mathrm{~mm}$ thick and (b) the window instead has a double pane of glass (a "thermopane"), in which each pane is $2.0 \mathrm{~mm}$ thick, with an intervening air space of $1.0 \mathrm{~mm} ?$ (Assume that there is a constant temperature difference and consider conduction only.)

Key Concepts

Composite Thermal Resistance

Composite thermal resistance is used to analyze heat transfer through materials that consist of multiple layers with different thermal properties. Each layer has its own thermal resistance, and the total resistance is the sum of the resistances of the individual layers. This concept is crucial when dealing with structures like double-pane windows, where the presence of multiple layers and intervening air gaps changes the overall heat transfer characteristics.

Thermal Conduction

Thermal conduction is the process by which heat energy is transferred within or between bodies due to a temperature difference, occurring at the molecular level as kinetic energy is passed between adjacent particles. This mechanism is central in understanding how heat flows through materials like glass and air, and it forms the basis for calculating energy loss or gain in structures.

Fourier's Law

Fourier's Law quantifies the rate at which heat is conducted through a material. It states that the heat flux is proportional to the negative gradient of temperature and the cross?sectional area through which heat is flowing, with thermal conductivity being the constant of proportionality. This law is fundamental when calculating heat transfer across both single-layer and composite materials.

Thermal Conductivity

Thermal conductivity is a material property that measures the ability of a substance to conduct heat. It appears in Fourier's Law and determines how much heat is transferred per unit time through a given area and temperature gradient. Different materials, such as glass and air, have distinct thermal conductivities that significantly affect the overall rate of heat transfer.
