A low-friction cart is placed between two identical springs...

A low-friction cart is placed between two identical springs that are attached to rigid walls, as shown in Figure $P 10.1$. If you push the cart against one spring and release it, it continues moving back and forth between the springs. Is this simple harmonic motion? Explain why or why not. Compare this case with the case where the cart is attached to the spring (such as the cart in Figure 10.8 ). Describe similarities and differences.

Key Concepts

Simple Harmonic Motion

Simple harmonic motion (SHM) is the type of periodic oscillatory motion where the net force acting on the system is proportional to the negative displacement from equilibrium, resulting in sinusoidal motion. This concept is foundational in understanding linear oscillatory systems and is characterized by a constant period and frequency, provided that the system remains within the linear region of its force law.

Hooke's Law

Hooke's law is a principle that describes the behavior of springs, stating that the force exerted by a spring is directly proportional to the displacement from its equilibrium position and acts in the opposite direction. This linear relationship is essential for producing the restoring force in systems undergoing simple harmonic motion.

Restoring Force Characteristics

A key aspect of simple harmonic motion is the nature of the restoring force, which must be continuously applied and linearly dependent on displacement. In systems where the restoring force is engaged only under specific conditions (for example, when a cart contacts a spring), the motion may approximate SHM in parts but can deviate from ideal behavior owing to discontinuities or piecewise linear force application.

Comparison of Constrained Motion

In the case of a cart attached to a spring, the restoring force is continuously in effect over the entire range of motion, leading to classic simple harmonic behavior with smooth sinusoidal oscillations. Conversely, when a free cart oscillates between two springs, the restoring force is only applied during the moments of contact with the springs, which introduces discontinuities. This can cause the overall motion to deviate from true SHM, even though the system may still exhibit oscillatory behavior that shares some similarities with it.
