A model airfoil of chord 6 in. and span 30 in. is placed in a wind tunnel with an air flow of $100 \mathrm{ft} / \mathrm{s}$ (the air is at $\left.70^{\circ} \mathrm{F}\right) .$ It is mounted on a cylindrical support rod 1 in. in diameter and 10 in. tall. Instruments at the base of the rod indicate a vertical force of 10 lbf and a horizontal force of 1.5 Ibf. Calculate the lift and drag coefficients of the airfoil.

Key Concepts

Dynamic Pressure

Dynamic pressure represents the kinetic energy per unit volume of a fluid flow and is calculated as one half of the product of the fluid density and the square of the velocity. It is an essential element in the analysis of aerodynamic forces, providing the bridge between measurable forces and dimensionless coefficients.

Lift Coefficient

The lift coefficient is a dimensionless number that characterizes the lift force produced by an airfoil relative to the dynamic pressure and a reference area. It is used to compare the aerodynamic efficiency of different airfoil shapes under similar flow conditions and is calculated by dividing the actual lift force by the product of dynamic pressure and reference area.

Drag Coefficient

The drag coefficient is a dimensionless number that quantifies the drag or resistance an object experiences as it moves through a fluid. This coefficient is determined by dividing the measured drag force by the dynamic pressure multiplied by the reference area, allowing designers to assess and compare the aerodynamic drag performance of various geometries.

Reference Area

The reference area is the specific area chosen to nondimensionalize aerodynamic forces like lift and drag, thereby facilitating the comparison of different airfoil geometries. For airfoils, this is typically the planform area, calculated as the product of chord length and span, and is essential in deriving meaningful coefficients in wind tunnel experiments.

Air Density and Temperature

Air density is the mass per unit volume of air and is influenced by temperature, pressure, and humidity. The temperature provided (in this instance, in Fahrenheit) allows for the determination of the air density, which is a crucial variable in calculating the dynamic pressure and, consequently, the aerodynamic coefficients in wind tunnel experiments.

Wind Tunnel Testing

Wind tunnel testing is an experimental method used to assess the aerodynamic characteristics of scale models under controlled flow conditions. By exposing an airfoil model to a prescribed airflow and measuring the forces acting on it, researchers can compute nondimensional coefficients like the lift and drag coefficients, which are vital for predicting the behavior of full-scale designs.
