A parallel plate capacitor has the space between its plates filled by two slabs of thickness $(\mathrm{d} / 2)$ each and dielectric constant $\mathrm{K}_{1}$ and $\mathrm{K}_{2}$ If $\mathrm{d}$ is the plate separation of the capacitor, then capacity of the capacitor is .......... (A) $\left[\left(2 \mathrm{~d} \in_{0}\right) / \mathrm{A}\right]\left[\left(\mathrm{K}_{1}+\mathrm{K}_{2}\right) /\left(\mathrm{K}_{1} \mathrm{~K}_{2}\right)\right]$ (B) $\left[\left(2 \mathrm{~A} \in_{0}\right) / \mathrm{d}\right]\left[\left(\mathrm{K}_{1} \mathrm{~K}_{2}\right) /\left(\mathrm{K}_{1}+\mathrm{K}_{2}\right)\right]$ (C) $\left[\left(2 \mathrm{Ad} \epsilon_{0}\right) / \mathrm{d}\right]\left[\left(\mathrm{K}_{1}+\mathrm{K}_{2}\right) /\left(\mathrm{K}_{1} \mathrm{~K}_{2}\right)\right]$ d] $\left(K_{1}+K_{2}\right)$ (D) $\left[\left(2 \mathrm{~A} \in_{0}\right) /\right.$

A parallel plate capacitor has the space between its plates filled by two slabs of thickness $(\mathrm{d} / 2)$ each and dielectric constant $\mathrm{K}_{1}$ and $\mathrm{K}_{2}$ If $\mathrm{d}$ is the plate separation of the capacitor, then capacity of the capacitor is ..........
(A) $\left[\left(2 \mathrm{~d} \in_{0}\right) / \mathrm{A}\right]\left[\left(\mathrm{K}_{1}+\mathrm{K}_{2}\right) /\left(\mathrm{K}_{1} \mathrm{~K}_{2}\right)\right]$
(B) $\left[\left(2 \mathrm{~A} \in_{0}\right) / \mathrm{d}\right]\left[\left(\mathrm{K}_{1} \mathrm{~K}_{2}\right) /\left(\mathrm{K}_{1}+\mathrm{K}_{2}\right)\right]$
(C) $\left[\left(2 \mathrm{Ad} \epsilon_{0}\right) / \mathrm{d}\right]\left[\left(\mathrm{K}_{1}+\mathrm{K}_{2}\right) /\left(\mathrm{K}_{1} \mathrm{~K}_{2}\right)\right]$
d] $\left(K_{1}+K_{2}\right)$
(D) $\left[\left(2 \mathrm{~A} \in_{0}\right) /\right.$

Key Concepts

Series Combination of Dielectric Layers

In configurations where dielectric layers are arranged sequentially (stacked along the direction of the electric field, such as layers placed between capacitor plates), they act as capacitors connected in series. In a series combination, the reciprocal of the total capacitance equals the sum of the reciprocals of the individual capacitances, a concept that is crucial for calculating the effective capacitance of a system with multiple dielectric media.

Composite Dielectrics in Capacitors

When a capacitor is filled with more than one dielectric material, each with its own dielectric constant and thickness, the overall effect on the capacity is determined by combining the contributions of the individual layers. This often involves considering the dielectric layers as capacitors either in series or parallel depending on their geometrical arrangement, which then dictates the effective capacitance.

Parallel Plate Capacitor

A parallel plate capacitor is an electrical component consisting of two conductive plates separated by an insulating material (dielectric). Its capacitance is determined by the area of the plates, the distance between them, and the permittivity of the medium filling the space, making it a fundamental example in electrostatics and circuit analysis.

Dielectric Constant (Relative Permittivity)

The dielectric constant, or relative permittivity, is a dimensionless parameter that describes how much a dielectric material increases the capacitance of a capacitor compared to vacuum. It reflects the material's ability to polarize in response to an electric field, thereby reducing the effective field within the capacitor and increasing its capacity to store electrical energy.
