00:01
For this problem on the topic of motion in two dimensions, we are given the coordinates as functions of time for a particle that is moving in the xy plane, where x of t is r into omega -t minus sine omega -t, and y of t is equal to r into 1 minus the cosine of omega -t.
00:18
We first want to find the sketch the trajectory of the particle, and we are told that this trajectory can be looked at as the point on the rim of a wheel that is rolling at constant speed on a horizontal surface.
00:29
We then want to find the velocity components and the acceleration components of the particle at any time t.
00:37
We want to then find the times at which the particle is momentarily addressed, the coordinates at these times, and the magnitude of the acceleration at these times.
00:48
Lastly, we want to know if the magnitude of the acceleration depends on time.
00:53
So firstly, to sketch the motion of the stretch of the particle, we know that the velocity or the x and y components positions are given.
01:08
So sketching the motion or the trajectory of this particle on a tire looks as follows.
01:23
So that's the xy trajectory of the particle.
01:29
Now in part b, we want to find the velocity and acceleration components at any time t.
01:38
Now we know that the velocity components will just be the first derivative of x and y with respect to time.
01:47
So using the position functions above, we know vx will be dx d t, which is r times omega, remember, which are both constants, into one minus the cosine of omega -t.
02:14
The y component of velocity v y will be d .y d t and the time derivative of the y function is r omega sine omega t...
