A particle moving along a plane curve has a position vector 𝐫, a velocity 𝐯, and an acceleration

step 1 In this question it is told that a ball is dropped from the top of a building and it takes 0 .5

A particle moving along a plane curve has a position vector...

A particle moving along a plane curve has a position vector $\mathbf{r},$ a velocity $\mathbf{v},$ and an acceleration a. Unit vectors in the $r$ - and $\theta$ -directions are $\mathbf{e}_{r}$ and $\mathbf{e}_{0},$ respectively, and both $r$ and $\theta$ are changing with time. Explain why each of the following statements is correctly marked as an inequality. $$\begin{array}{lll} \dot{\mathbf{r}} \neq v & \ddot{\mathbf{r}} \neq a & \dot{\mathbf{r}} \neq \dot{r} \mathbf{e}_{r} \\ \dot{r} \neq v & \ddot{r} \neq a & \ddot{\mathbf{r}} \neq \ddot{r} \mathbf{e}_{r} \\ \dot{r} \neq \mathbf{v} & \ddot{r} \neq \mathbf{a} & \dot{\mathbf{r}} \neq r \dot{\theta} \mathbf{e}_{\theta} \end{array}$$

A particle moving along a plane curve has a position vector $\mathbf{r},$ a velocity $\mathbf{v},$ and an acceleration a. Unit vectors in the $r$ - and $\theta$ -directions are $\mathbf{e}_{r}$ and $\mathbf{e}_{0},$ respectively, and both $r$ and $\theta$ are changing with time. Explain why each of the following statements is correctly marked as an inequality.
$$\begin{array}{lll}
\dot{\mathbf{r}} \neq v & \ddot{\mathbf{r}} \neq a & \dot{\mathbf{r}} \neq \dot{r} \mathbf{e}_{r} \\
\dot{r} \neq v & \ddot{r} \neq a & \ddot{\mathbf{r}} \neq \ddot{r} \mathbf{e}_{r} \\
\dot{r} \neq \mathbf{v} & \ddot{r} \neq \mathbf{a} & \dot{\mathbf{r}} \neq r \dot{\theta} \mathbf{e}_{\theta}
\end{array}$$

Key Concepts

Polar Coordinate System

This system represents a point in the plane using a distance (r) and an angle (?) rather than x and y coordinates. In such a system, the position vector is expressed in terms of r and ?, and because both these coordinates change with time, their time derivatives contribute differently to the particle’s motion.

Vector vs Scalar Quantities

A fundamental concept in kinematics is the distinction between vectors and scalars. Quantities like the velocity vector (v) and acceleration vector (a) have both magnitude and direction, while rates such as ?? (which is the time derivative of the magnitude r) are scalars. Therefore, equating them (e.g., ?? ? v) is incorrect because it ignores the directional information.

Time Derivatives in Polar Coordinates

When differentiating in polar coordinates, it is critical to recognize that the unit vectors (e_r and e_?) themselves change with time. This means that the derivative of the position vector involves not only the derivatives of the scalar components (r and ?) but also the derivatives of the unit vectors. The terms r??e_? and r??_r appear as a result, which shows why simply differentiating the scalar coordinate (such as taking ??e_r) does not capture the full vector behavior.

Decomposition of Velocity and Acceleration

The velocity vector in polar coordinates is composed of a radial component (??e_r) and a transverse component (r??e_?). Similarly, the acceleration vector includes contributions due to the change in the magnitude and the direction of the velocity. This decomposition illustrates why expressions like ?? or ?? alone are not equivalent to the total speed (v) or total acceleration (a), as they omit components contributed by the angular motion.
