A person shuffling across a dry carpet can be approximately...

A person shuffling across a dry carpet can be approximately modeled as a charged 100 -pF capacitance with one end grounded. If the person touches a grounded metallic object such as a water faucet, the capacitance is discharged and the person experiences a brief shock. Typically, the capacitance may be charged to $20,000 \mathrm{V}$ and the resistance (mainly of one's finger) is $100 \Omega$. Determine the peak current during discharge and the time constant of the shock.

Key Concepts

Peak Current in Discharge

The peak current during the discharge of a capacitor occurs at the moment when the stored energy begins to be released and is determined by the initial voltage across the capacitor divided by the resistance in the discharge path. This concept is important when analyzing sudden current surges, as it helps predict the initial impact of energy transfer in transient events.

RC Circuit

An RC circuit is an electrical circuit composed of resistors and capacitors. It is widely used to model and analyze the time-dependent behavior of charging and discharging processes. The interaction between resistance and capacitance in these circuits defines key dynamics such as the rate at which voltages rise or fall, making RC circuits central to the study of transient responses in electronics.

Time Constant

The time constant, defined as the product of resistance and capacitance (? = RC), characterizes the rate at which voltages or currents in an RC circuit exponentially decay. It provides a measure of the response speed of a system, indicating how quickly a system transitions from one state to another following a disturbance. Understanding the time constant is essential for designing circuits with desired transient characteristics.

Capacitance

Capacitance is the ability of a system to store electrical energy in the form of an electric field. It is a fundamental property of components such as capacitors in circuits and affects how much charge can be stored at a given voltage. This concept is crucial in understanding transient electrical behaviors, particularly in systems where energy is accumulated and then released rapidly.

Resistance

Resistance is a measure of the opposition to the flow of electric current through a conductor. It plays a critical role in determining the current in a circuit and in dissipating energy as heat. In transient phenomena, such as the discharge of a capacitor, resistance directly influences both the magnitude of the current and the rate at which electrical energy is released.
