A power plant taps steam superheated by geothermal energy to 505 $\mathrm{K}$ (the temperature of the hot reservoir) and uses the steam to do work in turning the turbine of an electric generator. The steam is then converted back into water in a condenser at 323 $\mathrm{K}$ (the temperature of the cold reservoir), after which the water is pumped back down into the earth where it is heated again. The output power (work per unit time) of the plant is 84000 kilowatts. Determine (a) the maximum efficiency at which this plant can operate and $(\mathbf{b})$ the minimum amount of rejected heat that must be removed from the condenser every twenty-four hours.

Key Concepts

Carnot Efficiency

Carnot efficiency represents the maximum possible efficiency any heat engine can achieve when operating between two thermal reservoirs. It is determined solely by the reservoir temperatures and is calculated using the formula 1 - (T_cold/T_hot). This concept is crucial because it sets the theoretical upper limit on the conversion of heat into work as dictated by the second law of thermodynamics.

Heat Engine

A heat engine is a device that converts heat energy into mechanical work by exploiting the temperature difference between a hot source and a cold sink. It operates on a cycle where heat is absorbed from a high-temperature reservoir, part of which is converted into work, while the remainder is rejected to a lower temperature environment, in compliance with energy conservation principles.

Conservation of Energy

The principle of conservation of energy states that energy cannot be created or destroyed, only transformed. In the context of a heat engine, this means the total energy input as heat must equal the sum of the work output plus the rejected heat. This principle is fundamental for analyzing the energy flow within thermodynamic cycles.

Power and Energy Calculations

Power is defined as the rate at which work is performed or energy is transferred, typically measured in watts (joules per second). When assessing performance over a period of time, such as 24 hours, it is essential to multiply the power by the time duration to obtain the total energy or work done, which is necessary for comparing theoretical efficiency and practical energy requirements.

Waste Heat Rejection

Waste heat rejection is the process by which excess thermal energy, not converted into useful work, is expelled into a colder environment. This is an inherent aspect of any heat engine cycle and directly influences the overall efficiency of the system. Effective management of waste heat is important to maintain sustainable operation in thermodynamic systems.
