A pressure of 650 kPa pushes a piston of diameter 0.25 m with V=5 m / s. What is the volume disp

step 1 Here in this question we have area is equal to pi upon 4d square which is 0 .0 49087 meter squar

A pressure of 650 kPa pushes a piston of diameter 0.25 m...

A pressure of $650 \mathrm{kPa}$ pushes a piston of diameter $0.25 \mathrm{m}$ with $\mathrm{V}=5 \mathrm{m} / \mathrm{s}$. What is the volume displacement rate, the force, and the transmitted power?

Key Concepts

Pressure-Force Relationship

This concept states that the force exerted by a fluid on a surface is the product of the applied pressure and the area over which it acts. It is fundamental in fluid mechanics for calculating forces generated in systems like hydraulic presses, where knowing the pressure and contact area allows one to determine the resulting force on a piston or other component.

Piston Area Calculation

In many fluid and mechanical systems, the cross-sectional area of a circular piston is determined using the formula A = ?d²/4. This area is a crucial parameter for converting pressure into force and for determining the volume of fluid displaced when the piston moves.

Volume Flow Rate

The volume flow rate quantifies the volume of fluid passing through a section per unit time. In systems with moving pistons, it is calculated by multiplying the cross-sectional area of the piston by its velocity. This concept is essential for understanding how quickly hydraulic systems operate and for sizing components in fluid power applications.

Hydraulic Power Transmission

Transmitted power in hydraulic systems is determined by the product of the force applied and the velocity at which the piston or actuator moves, often expressed as power = force × velocity. This concept links mechanical energy transfer to fluid parameters, allowing the assessment of system efficiency and performance in applications ranging from machinery to vehicle systems.
