A rigid 50-L nitrogen cylinder is equipped with a safety...

A rigid $50-L$ nitrogen cylinder is equipped with a safety relief valve set at $1200 \mathrm{kPa}$. Initially, this cylinder contains nitrogen at $1200 \mathrm{kPa}$ and $20^{\circ} \mathrm{C}$. Heat is now transferred to the nitrogen from a thermal energy reservoir at $500^{\circ} \mathrm{C}$, and nitrogen is allowed to escape until the mass of nitrogen becomes one-half of its initial mass. Determine the change in the nitrogen's work potential as a result of this heating. Take $T_{0}=20^{\circ} \mathrm{C}$.

Key Concepts

Exergy (Work Potential)

Exergy, or available work, is the maximum useful work that can be extracted from a system as it comes into equilibrium with its environment. It accounts for the quality of energy in addition to its quantity and is crucial in evaluating the actual performance of thermodynamic processes. This concept is particularly significant because it establishes limits on the work potential available from a system undergoing changes, including those involving heat transfer and mass removal.

Reference State (Dead State)

The reference state, often referred to as the dead state, is the condition in which the system is in equilibrium with its surroundings, and no further work can be extracted. In exergy analysis, properties at this state (such as ambient temperature and pressure) serve as the baseline for determining the maximum possible work. This concept helps in quantifying how far a system is from equilibrium and can be used to assess the utility of energy available during a process.

Constant Volume Process in Rigid Containers

In processes that occur in a rigid container, the volume remains constant, which simplifies the energy analysis by eliminating the work associated with volume expansion. However, when a safety relief valve is present, mass can be exchanged with the surroundings to prevent pressure from exceeding set limits. This introduces additional considerations in calculating the change in work potential because the process involves not only heat transfer but also changes in the system’s mass and state properties.

Heat Transfer from a Thermal Reservoir

Heat transfer from an external thermal reservoir alters the internal energy and the state of the working fluid. When heat is added to a system, particularly at temperatures significantly higher than the ambient or reference temperature, it can increase the system's exergy if the process is reversible. However, in real processes—especially those involving irreversible mass discharge through relief valves—there can be a loss or degradation of available work, making it essential to analyze how heating impacts the work potential.

Ideal Gas Behavior and Thermophysical Properties

Understanding the behavior of the working fluid, in this case nitrogen, as an ideal gas is critical for the thermodynamic analysis. The ideal gas assumption allows the use of simplified relationships between pressure, volume, and temperature. Additionally, the specific properties of the gas (such as specific heat capacities) play a key role in determining how the fluid reacts to heating and mass loss, which in turn affects the change in its work potential.
